UL Certified Panel

Class I Division 2 AEx certified panel

We have achieved a significant accomplishment by successfully conceiving, producing, and delivering a UL certified Panel tailored for Class I Division 2. We take pride in catering to the needs of our valued client, a distinguished multinational entity with a footprint across the UAE, UK, and Australia. The renowned testing and certification organization, Intertek, has validated this product in accordance with the UL standard for Class I Division 2.

This specialized panel is dedicated to a filtration module package system designed to regulate turbines. It utilizes dedicated cards to control solenoid valves, incorporating two pressure gauges and a Dust control board. The system employs differentiation pressure switches to monitor blocks or slugs, triggering the operation of solenoid valves based on the received signals. To ensure safety in explosive environments, the panel features Pneumatic pressure inlet valves entering an Ex d explosion-proof enclosure, safeguarding the pressure inlets with appropriate modules.

Constructed with Ex db certified Copper-Free Aluminium Alloy of marine-grade quality, this panel boasts the following certifications:

  • CNC: Classified Enclosures for use in Class I Zone 1 Ex db IIB+H2 Gb, Class II Zone 21 Ex tb IIIC Db
  • USC: Classified Enclosures for use in Class I Zone 1 AEx db IIB+H2 Gb, Zone 21 AEx tb IIIC Db Hazardous Locations
  • Class I Division 2 Groups B, C, D, Class II Division 2 Groups F and G Type 1, 12, 4, and 4X
  • Ambient Temperature: -18 to +44 degrees Celsius.

Compliant with UL STD 508A and UL STD 121201, this UL certified panel stands as a testament to our expertise in tackling challenging projects, surpassing the norm of ATEX/IECEX certified panels. The completion of this prestigious project in the UAE showcases our commitment to delivering top-notch solutions for our customers in demanding environments.
